    15 Tons Heavy Load Battery Transfer Trolley Automatic Directional Casting Steel

    Ask Lasest Price
    Brand Name : Remarkable
    Model Number : RWP-15T
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 300 sets per year
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    15 Tons Heavy Load Battery Transfer Trolley Automatic Directional Casting Steel


    15 Tons Heavy Load Battery Transfer Trolley Automatic Directional Casting Steel


    Our Heavy Duty Platform Trolleys Are Synonymous With Advanced Customization And Adaptability For Cargo And Operators.Henan Remarkable 15 Tons Bay To Bay Battery Powered Die Transport Platform Design Flexibility Are Perfectly Suitable For A Complete Range Of Sectors And Applications With Particular Focus On Metalworking Industry, Tool And Dies Sector. We Designed Our Platform Truck Cart Series With Respect To Environment, Which Gives The Machine Greater Productivity As Well As Significant Saving In Maintenance And Consumables.

    Advantages

    (1) Maintenance-Free Battery.

    (2) Imported Speed Control Electronic Control, Two-Speed Control.

    (3) Imported Industrial Wireless Remote Control.

    (4) Convenient, Flexible And Environmentally Friendly.


    15 Tons Heavy Load Battery Transfer Trolley Automatic Directional Casting Steel


    Remarkable heavy duty platform carts are utilised to transfer large and bulky injection molds within production plants, in both medium and large sized companies. Especially in the automobile industry and mechanical equipment industry. These companies have numerous molds which on a daily basis must be transferred within the factory from a storage location to the molding presses, to maintenance rooms and so on. So, the most effective way is to use Battery power platform trolleys, Remarkable is a professional heavy duty platform carts manufacturer to improve their operations.


    Technical parameters for electric transfer carts
    1rated load(t)5101520304050150
    2impacted rated load(t)7.51522.530456075225
    3structure of framesteel plates welded, beam structure
    4max. wheel load(t)2.84.34.85.67.7101227
    5ground requirementcement floorsteel plate ground
    6table size(mm)3000×20003600×20004000×22004500×22005000×22005500×2300

    6000×

    2300

    10000×

    3000

    7height of the whole cart(mm)4505306006006507007001200
    8ground clearance(mm)5075
    9wheels base(mm)1500170018002000
    10axles distance(mm)250031003400390043004800520010000
    11turning radius(mm)250131013401390143014801520110001
    12turning typeturning while driving with no stop
    13control method for turningcontrol button
    14turning structuremechanical
    15motor power(Kw)3.556710121515
    16wheel diameter(mm)Ф300 x 4Ф350 x 4Ф400 x 4Ф400 x 6Ф500 x 6Ф600 x 8
    21battery modelD-250 x 24D-33 x 24D-400 x 24D-440 x 24D-250 x 36D-330 x 36D-440 x 36D-600 x 36
    22battery maintenancefree of maintenance
    23charger's installationinstalled on cartsplit-type
    24charger functionautomatic charging
    25radar control3-0.3m, automatic stop for obstacles
    26warning equipmentsound and light
    27other functionsturning light, night light and power display
