    Industrial 10T Rail Transfer Trolley Stainless Steel Motorized

    Ask Lasest Price
    Brand Name : Remarkable
    Model Number : KPD-10T
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : T/T, D/A, L/C, D/P, Western Union, MoneyGram
    Supply Ability : 300 sets per year
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    Industrial 10T Rail Transfer Trolley Stainless Steel Motorized

    Industrial 10T Rail Transfer Trolley Stainless Steel Motorized


    Industrial 10T Stainless Steel Motorized Rail Transfer Trolley Is One Kind Of Transfer Equipment For Stone Materials, Steel Rebar, Brick Kiln, Bridge Metal, Steel Pipe, Steel Tube, Hopper, Steel Billet, Steel Coil, Steel Plate, Injection Mold Steel Beam Transport In Steel Plant From Bay To Bay, And Mold Plant, Workshop Materials, Steel Bar, Steel Structure, Steel Plate, Steel Coil, Pallet, Pipe And Other Materials. There Are Some Power Supply Modes For Customers To Choose, Such As Battery Power, Cable Power, Low Voltage Rail Power, Busbar Etc.


    Industrial 10T Stainless Steel Motorized Rail Transfer Trolley​ Is With Security Features And Long Service Life. As For The Battery, The Battery Uses A Unique Divergent Grid Structure, Which Improves The Performance Of The Battery's High-Current Square Pad; The Battery Pole Uses An Embedded Large-Area Copper Core, Which Is Suitable For High-Current Discharge. Steel Transfer Cart Is A Kind Of Electric Transport Equipment That Runs On The Track. It Is A Commonly Used Transport Equipment In Heavy Industry. It Can Greatly Improve Work Efficiency And Is More Suitable For The Current Fast-Paced Life. It Is Often Used Inside The Plant As An Assembly Line, And Can Also Be Used Across The Factory Workshop.


    Industrial 10T Rail Transfer Trolley Stainless Steel Motorized

    Technical parameters for Low-voltage track powered electric transfer carts KPD series
    ModelKPD-6tKPD-10tKPD-16tKPD-25tKPD-40tKPD-63tKPD-100tKPD-160tKPD-200t
    Rated load (t)61016254063100160200
    Countertop size
    (mm)
    Length360036004000450050005600630080008200
    Width200020002200220025002500280028003000
    Height55055060065070085090011001250
    Speed(m/min)303030302525202018
    Wheel base A(mm)200022002200250028003200360050005000
    Track medial distance C(mm)143514351435143514351435165020002000
    Wheel diameter(mm)400400400500500600700700700
    Bottom clearance(mm)505050606060607070
    Minimum turning radius303550556080100100
    Motor model / power
    (Kw)

    KPD

    (single-phase)

    JDYP-11-6JDYP-12-6JDYP-21-6JDYP-22-6
    2.23.557.5

    KPD

    (three-phase)

    YZ132M1-6YZ132M2-6YZ160M1
    -6
    YZ160M2-6YZ160L-6YZ160M2
    -6
    YZ160L
    -6
    2.23.75.57.5112×7.52×11
    Power modeKPD380V reduced to 36V / 360V reduced to 36V then boosted to 380V
    Recommended track model24kg/m38kg/m43kg/mQU80QU100
    Number of wheels48
    Maximum wheel Pressure (t)1.913.214.877.511.516.927.622.828.5
    Reference weight (t)3.43.724.268.511.415.225.531.5

    Note: 1) Other gauges, table sizes and load tonnages can be customized according to user requirements;

    2) Imported and domestic industrial wireless remote-control devices are optional;

    3) Optional imported wireless two-speed control;

    4) Optional matching automatic parking, and alarming when encountering person 2 meters away.
