    Workshop Cast Iron Battery Operated 10 Tons Die Materials Transfer Cart

    Ask Lasest Price
    Brand Name : Remarkable
    Model Number : RWP-10T
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 500 sets per year
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    Workshop Cast Iron Battery Operated 10 Tons Die Materials Transfer Cart


    Workshop Cast Iron Battery Operated 10 Tons Die Materials Transfer Cart


    The Battery Powered 10 Ton Material Transfer Cart On Cement Floor Have Been Conceived And Built To Realize Their Utmost Working Flexibility. Because They Have No Predefined Path And Can Steer In Any Direction And Move On Any Kind Of Floor. And These Die Transfer Car Are Very Useful To Bring The Heavy Loads Where Overhead Cranes Cannot Arrive.


    Advantages Of 1-150 Ton No Rail Transfer Trolley:

    1. High Level Automation (Self Propelled/Steerable)

    2. The Largest Capacity Can Reach To 100t

    3. Safe Parts Are Installed In The Transfer Cart (Warning Light, E-Stop, Buffer...)

    4. Robust Sturdy Cart Frame

    5. AC/DC Electric Engine, Diesel Engine Or Pneumatic Engine

    6. Excellent Gear Reducer And Motor With High Quality, Assembled Together Perfectly

    7. Remote Control & Hand Pendant Control Make The Operation More Convenient

    8. The Speed Can Be Adjusted

    9. Easy Operation And Maintenance

    10. Famous Brand Parts, Guarantee The Quality And Prolong The Using Lifetime

    11. Low Noise And Do Not Pollute The Environment

    Workshop Cast Iron Battery Operated 10 Tons Die Materials Transfer Cart


    Technical parameters for electric transfer carts
    1rated load(t)5101520304050150
    2impacted rated load(t)7.51522.530456075225
    3structure of framesteel plates welded, beam structure
    4max. wheel load(t)2.84.34.85.67.7101227
    5ground requirementcement floorsteel plate ground
    6table size(mm)3000×20003600×20004000×22004500×22005000×22005500×2300

    6000×

    2300

    10000×

    3000

    7height of the whole cart(mm)4505306006006507007001200
    8ground clearance(mm)5075
    9wheels base(mm)1500170018002000
    10axles distance(mm)250031003400390043004800520010000
    11turning radius(mm)250131013401390143014801520110001
    12turning typeturning while driving with no stop
    13control method for turningcontrol button
    14turning structuremechanical
    15motor power(Kw)3.556710121515
    16wheel diameter(mm)Ф300 x 4Ф350 x 4Ф400 x 4Ф400 x 6Ф500 x 6Ф600 x 8
    21battery modelD-250 x 24D-33 x 24D-400 x 24D-440 x 24D-250 x 36D-330 x 36D-440 x 36D-600 x 36
    22battery maintenancefree of maintenance
    23charger's installationinstalled on cartsplit-type
    24charger functionautomatic charging
    25radar control3-0.3m, automatic stop for obstacles
    26warning equipmentsound and light
    27other functionsturning light, night light and power display

    The 10 Tons Workshop Cast Iron Battery Die Transfer Trolley Is A Kind Of Material Handling Tool, Applied In The Workshop For Material And Die Handling. The Battery Transfer Trolley Also Known As Steerable Transfer Trolley, It Is The Perfect Device Where Clients Require Delicate Handling Solutions In Very Narrow Spaces.


    Application

    This Kind Of Electric Handling Bogie Usually Be Used As One Automated Transport Vehicle For Factory Transportation To Carry Various Heavy Stuff And Workpiece. As Customers' Working Environment These Transfer Carts Equipment Can Be Used In High-Temperature, Anti-Explosion Or Other Sever Condition With Strong Bearing Capacity. These Material Handling Equipment Are More Suitable For That High Using Frequency And Long Running Distance. Normally, The Hydraulic Lifting Device And PLC Control System Could Be Added On The Motorized Handling Transfer Carts To Meet Special Using Condition.

    Workshop Cast Iron Battery Operated 10 Tons Die Materials Transfer Cart
