    Aluminum Ingots Heavy Duty Transfer Cart 5 Tons Lithium Battery

    Ask Lasest Price
    Brand Name : Remarkable
    Model Number : RWP
    Certification : CE, ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 600
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    Aluminum Ingots Heavy Duty Transfer Cart 5 Tons Lithium Battery

    Aluminum Ingots Heavy Duty Transfer Cart 5 Tons Lithium Battery


    The employees who operate the electric flat car need to be familiar with the structural performance of the equipment and can operate independently only after passing the test. When transporting heavy objects, they shall be placed stably and gently to ensure uniform weight distribution, and the equipment shall not be used beyond the specification or overload. When changing the running direction during use, the reverse start can be carried out only after the movement stops. The operator of low-voltage track electric flat car shall also inspect the equipment of electric flat car according to relevant inspection requirements. In addition, the lubrication shall be carried out in strict accordance with the lubrication chart of the electric flat car, and it shall be carried out at a fixed time and at a fixed point. The operating staff shall carefully realize the "four skills" (being able to use, check, maintain and eliminate faults) and the "Three Virtues" (being able to use, manage and repair). After use, the load shall be unloaded, the power supply shall be cut off, and the cleaning shall be carried out according to the system. The operation of each part shall be checked regularly. If the temperature of motor and bearing is too high or there is abnormal sound, it is necessary to stop in time for inspection.


    Aluminum Ingots Heavy Duty Transfer Cart 5 Tons Lithium Battery


    Technical parameters for electric transfer carts
    1rated load(t)5101520304050150
    2impacted rated load(t)7.51522.530456075225
    3structure of framesteel plates welded, beam structure
    4max. wheel load(t)2.84.34.85.67.7101227
    5ground requirementcement floorsteel plate ground
    6table size(mm)3000×20003600×20004000×22004500×22005000×22005500×2300

    6000×

    2300

    10000×

    3000

    7height of the whole cart(mm)4505306006006507007001200
    8ground clearance(mm)5075
    9wheels base(mm)1500170018002000
    10axles distance(mm)250031003400390043004800520010000
    11turning radius(mm)250131013401390143014801520110001
    12turning typeturning while driving with no stop
    13control method for turningcontrol button
    14turning structuremechanical
    15motor power(Kw)3.556710121515
    16wheel diameter(mm)Ф300 x 4Ф350 x 4Ф400 x 4Ф400 x 6Ф500 x 6Ф600 x 8
    21battery modelD-250 x 24D-33 x 24D-400 x 24D-440 x 24D-250 x 36D-330 x 36D-440 x 36D-600 x 36
    22battery maintenancefree of maintenance
    23charger's installationinstalled on cartsplit-type
    24charger functionautomatic charging
    25radar control3-0.3m, automatic stop for obstacles
    26warning equipmentsound and light
    27other functionsturning light, night light and power display


    Henan Remarkable Intelligent Technology Co., Ltd is a professional handling equipment company integrated intelligent R&D, design, manufacturing, sales as well as after-sales service. It specializes in producing electric transfer carts of various tonnages, handling equipment accessories, intelligent crane and crane accessories with professional design, development and manufacture of non-standard, intelligent electric transfer carts and handling robots. According to different power mode, the handling equipment products can be divided into six series including low-voltage track-powered, battery-powered, towline-powered, cable reel-powered, safe-trolley-line powered, and unpowered traction.
