Pallet Transfer Cart Rail Transport Platform
Pallet transfer car is powered by low voltage electricity from railways or battery-powered, the kind of transfer car is one of the most convenient and it often can be widely used in the industry field and so on. Of course, compared to other transfer equipment, its main features are as follows, its rails are insulated with the ground, and its wheels are insulated with the ground, so don't others.it is the advantage that the tracks carriage has, why we design is that its convenient (only rails needed) and its simple operation. About us, Our company have professional team and utilize more advanced technique to make it, and it has been a long year to manufacture it attentively. Simultaneously, it will be easier and more flexible. Due to no cable limitation, the running distance of the transfer vehicle is not limited, and the speed can also be adjusted as required. Simple structure and low cost make it popular for workshop transportation. The Pallet Handling Transfer Car can be applied on the occasion with any loading capacity and high using frequency.
Remarkable Pallet Handling Transfer Car not only has sold across the country but also exported to US, Germany, Thailand, Singapore, South Africa, Turkey, Sri Lanka, etc. We are a professional manufacturer of material transfer carts with more than 17 years' experience. According to your needs, we can customize manufacture transfer carts for any application. Our company passed the ISO9001 Quality management system and got the CE, SGS certificate.
Contact Us For A Free Consultation Based On Your Requirements. Remarkable Sells Its Pallet Transfer Cart Rail Transport Platform Worldwide!
| Technical parameters for Battery powered electric transfer carts KPX series | ||||||||||
| Model | KPX-2t | KPX-5t | KPX-10t | KPX-20t | KPX-25t | KPX-30t | KPX-40t | KPX-50t | KPX-150t | |
| Rated Load(t) | 2 | 5 | 10 | 20 | 25 | 30 | 40 | 50 | 150 | |
| Table Size(mm) | Length | 2000 | 3500 | 3600 | 4000 | 4500 | 4500 | 5000 | 5500 | 10000 |
| Width | 1500 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 3000 | |
| Height | 450 | 500 | 500 | 550 | 600 | 600 | 650 | 650 | 1200 | |
| Wheel Base(mm) | 1200 | 2500 | 2600 | 2800 | 3200 | 3200 | 3800 | 4200 | 7000 | |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | |
| Wheel Diameter(mm) | Ø270 | Ø300 | Ø300 | Ø350 | Ø400 | Ø400 | Ø500 | Ø500 | Ø600 | |
| Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 8 | |
| Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | |
| Running Speed(m/min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-18 | |
| Motor Power (Kw) | 1 | 1.2 | 1.6 | 2.2 | 3 | 3.5 | 4 | 5 | 15 | |
| Battery Capacity (Ah) | 180 | 180 | 180 | 180 | 250 | 250 | 300 | 330 | 600 | |
| Battery Voltage(V) | 24 | 36 | 48 | 48 | 48 | 48 | 48 | 48 | 72 | |
| Running Time When Full Load | 4.32 | 5.4 | 4.8 | 4 | 4 | 3.5 | 3.6 | 3.3 | 2.9 | |
| Running Distance for One Charge (Km) | 6.5 | 8.1 | 7.2 | 4.8 | 4.8 | 4.2 | 4.3 | 4 | 3.2 | |
| Max Wheel Load (KN) | 14.4 | 25.8 | 42.6 | 77.7 | 94.5 | 110.4 | 142.8 | 174 | 266 | |
| Reference Weight(t) | 2.8 | 3.6 | 4.2 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 27 | |
| Recommended Rail Model | P15 | P18 | P18 | P24 | P38 | P38 | P43 | P43 | QU100 | |
1. Load capacity, table size, and rail gauge can be customized; | ||||||||||
Functions & Advantages Of Pallet Handling Transfer Cart
The Pallet Handling Transfer Car is Anti-high temperature, Anti-high explosion;
The Pallet Handling Transfer Car is powered by a battery or Low voltage rail power supply;
With lifting holes, Pallet Handling Transfer Car is convenient for shipment;
The Pallet Handling Transfer Car has a feature of stable start, big starting power, long lifetime;
The Pallet Handling Transfer Car can run on the C-form track or S-form track;
Running distance of Pallet Handling Transfer Car is unlimited;
Safe and convenient operation is available for Pallet Handling Transfer Car;
High using frequency for Pallet Handling Transfer Car.
Application Site
Application Sites Of Pallet Handling Transfer Car
The Pallet Handling Transfer Car is mainly applied in assembly line(ring production line,loop production line),metallurgy industry(steel lade),warehouse transport,ship industry(maintenance, assemcle,container transport),work piece transport in workshop,lathe transport,steel factory(steel billet,steel plate,steel coil,steel pipe,section steel structure),construction(bridge,simple building,concrete column,)petroleum industry(oil pump,sucker rod and parts),energy(polycrystalline silicon,generator,windmill),chemical industry(electrolytic cell,retort etc),railway(rail maintenance,rail welding,train tractor).
|
|
