    Transfer Trolley 5 Tons Heavy Load For Steel Manufacturing Workshop

    Ask Lasest Price
    Brand Name : Remarkable
    Model Number : RWP, AGV, KPX
    Certification : CE SGS ISO
    Price : Price negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 600 sets per year
    Delivery Time : 40-45 work days
    • Product Details
    • Company Profile

    Transfer Trolley 5 Tons Heavy Load For Steel Manufacturing Workshop


    Transfer Trolley 5 Tons Heavy Load For Steel Manufacturing Workshop


    Transfer Trolley 5 Tons Heavy Load For Steel Manufacturing Workshop Is Equipped With V-Shaped And Rollers On The Electric Coil Transfer Cart To Protect The Stability Of The Coil. The V-Shaped Support And Roller Can Also Be Removed From The Cart For Other Purposes. Cargo Freight. The Distance Of The Roller Can Be Adjusted According To The Diameter Of The Coil. The Aluminum Material Handling Equipment Was Developed To Greatly Reduce The Material Handling Requirements Of Cranes And Forklifts, While Providing Fast, Safe And Smooth Material And Product Transportation Through Manufacturing Facilities.


    It Is One Kind Of Transfer Equipment That Can Move Vertically And Horizontally For Stone Materials,Steel Rebar, Brick Kiln,Bridge Metal,Steel Pipe, Steel Tube,Hopper,Steel Billet,Steel Coil, Steel Plate, Injection Mold Steel Beam Transport In Steel Plant From Bay To Bay, And Mold Plant,Workshop Materials, Steel Bar, Steel Structure ,Steel Plate,Steel Coil,Pallet,Pipe And Other Materials.There Are Some Power Supply Modes For Customers To Choose, Such As Battery Power, Cable Power, Low Voltage Rail Power, Busbar Etc.


    Customized Trackless transfer cart technical parameter:


    No.ModelRWP trackless transfer cart
    1Load(t)10
    2Table size(mm)6000×2500
    3Height(mm)600
    4Ground clearance(mm)100
    5Ground-typeCement floor, Self-leveling
    6Climbing slopeNo more than 2 degrees
    7Move WayForward, backward and rotate 360 degrees,turning while driving with no stop
    8Operation methodWireless remote control & Hand operate pendant
    9Traveling speed(m/min)No-load 30, load 10
    10Power supplybattery
    11Brake modeElectromagnetic brake
    12Battery model48V120Ah
    13Charger install typeSplit-type
    14Battery charger functionAutomatic charging
    15Safety deviceAudible and visual alarm lamp and emergency stop button, Ultrasonic obstacle avoidance
    16Other functionsWarning light, power display, over-voltage, under-voltage, over-current protection

    The electric flat car has simple structure, strong application level, strong bearing capacity, not afraid of dirt, simple maintenance and long service life. It has the advantages of compact structure, strong carrying capacity, accurate positioning, high automatic process flow, easy operation, smooth turning and driving, strong climbing, long-distance driving, low noise, convenient maintenance, remote control, etc. It is suitable for various transportation. Environment, such as high temperature, explosion-proof special occasions, paint room, sandblasting room, people do not go, the electric flat car can go in and work quickly.
