    15 Tons Steerable Trackless Transfer Car For Material Handling

    Ask Lasest Price
    Brand Name : Remarkable
    Model Number : RWP-15T
    Certification : CE, ISO9001
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 400 sets per year
    Delivery Time : 30-45 work days
    • Product Details
    • Company Profile

    15 Tons Steerable Trackless Transfer Car For Material Handling


    15 Tons Steerable Trackless Transfer Car For Material Handling


    Product Brief About 15 Tons Steerable Trackless Transfer Car For Material Handling

    * The Steerable Transfer Cart Series Is A Kind Of Trackless Material Handling Car.
    * It Is Powered By Storage Battery, Which Is Ideal For Moving Materials, Dies, Coils Or Working In Progress Throughout A Manufacturing Facility Without Limitations To Track Length And Distance.
    * The Cart Is Installed And Equipped With Battery And Intelligent Charger Respectively.
    * There Is PLC Program And Speed Controller Which Enables The Transfer Cart To Move Forward,Backward, Turn Left Or Right And,Adjust Speed Accordingly.
    * Our Standard Heavy-Duty Design Is Capable Of Transferring 50 Tons At 25m Per Minute With Small Turning Radius.


    We Conceives And Manufactures A Wide Range Of Railway Guided Transfer Carts, Battery Powered Trolleys, Intelligent Self-Propelled Trolleys, Die Carts, Industrial Flat Trailers, Tilters And Lifting Platforms That Operate In Many Industrial Fields: Metallurgy, Manufacture, Oil And Gas, Die Shops, Shipyards, Chemical Plant, Automotive, Mining Industry, Aerospace, Power Generation, Coal Industry, Paper Mills, Metalworking, Warehouse And Many Others!


    Wireless Control Industrial Transfer Trolley


    Remarkable heavy duty platform carts are utilised to transfer large and bulky injection molds within production plants, in both medium and large sized companies. Especially in the automobile industry and mechanical equipment industry. These companies have numerous molds which on a daily basis must be transferred within the factory from a storage location to the molding presses, to maintenance rooms and so on. So, the most effective way is to use Battery power platform trolleys, Remarkable is a professional heavy duty platform carts manufacturer to improve their operations.


    Technical parameters for electric transfer carts
    1rated load(t)5101520304050150
    2impacted rated load(t)7.51522.530456075225
    3structure of framesteel plates welded, beam structure
    4max. wheel load(t)2.84.34.85.67.7101227
    5ground requirementcement floorsteel plate ground
    6table size(mm)3000×20003600×20004000×22004500×22005000×22005500×2300

    6000×

    2300

    10000×

    3000

    7height of the whole cart(mm)4505306006006507007001200
    8ground clearance(mm)5075
    9wheels base(mm)1500170018002000
    10axles distance(mm)250031003400390043004800520010000
    11turning radius(mm)250131013401390143014801520110001
    12turning typeturning while driving with no stop
    13control method for turningcontrol button
    14turning structuremechanical
    15motor power(Kw)3.556710121515
    16wheel diameter(mm)Ф300 x 4Ф350 x 4Ф400 x 4Ф400 x 6Ф500 x 6Ф600 x 8
    21battery modelD-250 x 24D-33 x 24D-400 x 24D-440 x 24D-250 x 36D-330 x 36D-440 x 36D-600 x 36
    22battery maintenancefree of maintenance
    23charger's installationinstalled on cartsplit-type
    24charger functionautomatic charging
    25radar control3-0.3m, automatic stop for obstacles
    26warning equipmentsound and light
    27other functionsturning light, night light and power display
