    Hydraulic Lift 10 Tons Battery Powered Transport Trolley Remote Control

    Ask Lasest Price
    Brand Name : Remarkable
    Model Number : RXP, RWP
    Certification : CE, SGS, ISO
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 600 sets per year
    Delivery Time : 40-45 work days
    • Product Details
    • Company Profile

    Hydraulic Lift 10 Tons Battery Powered Transport Trolley Remote Control


    Hydraulic lift 10 Tons battery powered transport trolley remote control


    10 Tons Motorized Mould Transport Cart With Hydraulic Lift Is Achieved With A Special Running Mechanism. Free Steering Is Not Limited By Space And Ground. It Can Change The Direction And Route Of Travel At Any Time. It Is Very Suitable For Use In The Field Where The Running Route Is Not Fixed. The Trackless Battery Electric Flat Car Uses High-Strength Polyurethane Rubber Wheels As The Drive Wheel And The Load-Bearing Wheel, Which Is Very Wear-Resistant And Has A Low Maintenance Cost.


    Automated Die Transfer System Cart Is Very Popular Transport Solution In Mold Manufacturing Industry.
    The Cart System Can Be Controlled By Push Button Pendant Or Remote Control.
    It Can Steer Freely On Plane Floor With 360 Degrees
    The Table Size Custom According The Mold Dimension
    Running Speed Can Be Adjusted From 0-15m/Min
    DC Motor Driven

    Technical parameters for trackless electric transfer carts
    Rated load(t)5101520304050150
    Impacted rated loa(t)7.51522.530456075225
    Structure of framesteel plates welded, beam structure
    Max. wheel load(t)2.84.34.85.67.7101227
    Ground requirementcement floorsteel plate ground
    Table size(mm)3000×
    2000
    3600×
    2000
    4000×
    2200
    4500×
    2200
    5000×
    2200
    5500×
    2300
    6000×
    2300
    10000×
    3000
    Height of the whole cart(mm)4505306006006507007001200
    Ground clearance(mm)5075
    Turning radius(mm)250131013401390143014801520110001
    Turning typeturning while driving with no stop
    Control method for turningcontrol button
    Turning structuremechanical
    Wheel materialZG55+hydropur ture
    Running speed(m/min)0-150-12
    Brake principleelectric magnetic brake
    Operation methodwith wire or no wire
    Battery modelD-250x24D-33x24D-400x24D-440x24D-250x36D-330x36D-440x36D-600x36
    Battery maintenancefree of maintenance
    Charger's installationinstalled on cartsplit-type


    Electric platform trolley, also known as an electric transfer vehicle, level car, trolley, cross-train, electric rail cart, climbing train, etc., is a factory-in-vehicle electric transport vehicle, first, it is an orbital type transport trolley, It is necessary to lay the rails on the ground, and the track is generally the trailer surface contact rail; second it is an electrically driven platform trolley, automatically runs under the motor reducer, and again it is a flat plate, the countertop is flat, and in special cases, It can also be a non-planar but invisible cover, and there is no steering wheel without a steering wheel (even if the turn is turned by track). Such vehicles have simple structures, convenient use, large load capacity, are not afraid of dirty, are easy to maintain, long service life, etc., because of their convenience, strong, economic, practical, easy cleaning and other advantages, etc., become internal and factory buildings Short-distance fixed-point frequent vehicle transportation tools between the factory buildings.

    Electric platform trolley main applications and electricity and drop in water blank cars, etc. Transport vehicles, electric dump trucks, electric sanitation products, etc. Electric transport vehicles and electric dump trucks are also applied to flour plants, distributors, foundry, chemical plants, furnace materials, farms, etc.
